Center Draft Lamp Flame Spreaders


     .    .

World's Largest Selection of Wicks!
      Wicks for virtually every heater, stove and lamp made since 1850

Photo Album

Heater and Lamp Flame Spreaders

Flame Spreaders from Heaters in the Past 100 Years

The following is a small sample of lamp flame spreaders.  This page is a work in progress as I find the time to finish it.
Left to right:  Admiral, Rayo #22, B&H 1904, Naugatuck, Miller, Improved Bristol, B&H 6.2.96, B&H 7.1.90.

`

Size comparison, left to right, E&G #0, Standard, Miller #1, Radiant #4, Radiant #5.

`

Flame spreaders from the smallest to the largest, from left to right:  Kosmos #15; P&A Royal; B&H; Beatrice 4012; Valor 420 Parlor Stove; and a Perfection 730.

More detailed lamp flame spreader photos.  Click on the photo to enlarge.

Admiral, H B & H

 Admiral, H B & H B&H "Tiny" B&H "Tiny"
Rex, "Tiny" B&H Rex, "Tiny" B&H B&H Radiant 5 B&H Radiant 5

B&H #2, 1890 "Jauch"

 B&H #2, 1890 B&H #89 B&H #89



B&H Radiant 4

 B&H Radiant 4   Ditmar Soleil

Improved Bristol Improved Bristol Improved Bristol Improved Bristol

The most beautiful

 Bristol Brass E&G 15''' E&G 15'''
Miller #2 Vestal #1 Miller Vestal #1 Miller Dresden
Craighead & Kintz Craighead & Kintz New Columbia
(Matthews & Willard)		 New Columbia
P&A Naugatuck P&A Naugatuck P&A Royal #2 P&A Royal #2
P&A Royal #1 P&A Royal #1 Banner Electric Banner Electric

As-new P&A Royal #1 P&A No. 1 Side P&A No. 1 inside
P&A Plumwood after 1905 P&A Plumwood "Columbia" FS, made by P&A for M&W... ...and sold by Trenton Lamp Co.
Banner #3 Banner #3 Pittsburgh Mammoth Pittsburgh Mammoth
Rayo Long Rayo Long Rayo Short Rayo Short
Rayo, 1st year Rayo 1905 Rayo Socony Rayo 22

Perfection - pre-Rayo Perfection - pre-Rayo
Rochester #2 Rochester #2 Rochester 1887 Rochester 1887
Standard Standard Success Success
Unidentified Veritas 30''' Unidentified W&W Agni
15''' Gaudard Matador 15''' Gaudard Matador 16''' CarolyBrenner 16''' CarolyBrenner


Hinks 20''' Young's Court 20''' L&B 20'' L&B 30''
Making a post-type flame spreader requires several different machine tools, including a metal shaper and a lathe. This series of photos was taken as the work progressed by Peter Brickell.
At left, an 18''' Vulcan reproduction flame spreader which was used as a sample for dimensions.  At right is a brand new Vulcan flame spreader, but the story is in getting to that point!  Note that the flame spreader is at the correct height for the Vulcan chimney.
The post is turned on a lathe. A metal shaper was used for the top of the post. The disk is attached to the top of the post. The new flame spreader fits the tube perfectly.
